£516.65 – £541.73
A single-lap interlocking concrete tile with the classic clay pantiles profile and bullnosed leading edge design with the characteristic profile of traditional clay pantiles.
25° minimum pitch available for smooth finish tiles; granular finish tiles have a higher minimum pitch requirement.
Grey & Red Tiles are Smooth
Antique Brown Tiles are Granular
Note: Shipping across all products will be calculated and combined at checkout.
| Size of tile | 387mm x 230mm | |
| Minimum pitch* | 30° Smooth (75mm headlap) 25° Smooth (100mm headlap) | 30° Granular (75mm headlap) |
| Maximum pitch | 90° | |
| Minimum headlap | 75mm | |
| Maximum gauge | 312mm | |
| Body thickness | 30mm (nominal) | |
| Overall depth | 71mm | |
| Cover width | 204mm (nominal) | |
| Hanging length | 370mm (nominal) | |
| Covering Capacity (net) | 15.7 tiles/m² at 75mm headlap 17.1 tiles/m² at 100mm headlap | |
| Weight of tiling (approx.) | 47kg/m² (0.46 kN/m²) at 75mm headlap 51 kg/m² (0.50 kN/m²) at 100mm headlap | |
| Battens required (net) | 3.2 lin.m/m² at 75mm headlap 3.5 lin.m/m² at 100mm headlap | |
| Batten size recommended | 38mm x 25mm for rafters/ supports not exceeding 450mm centres (fixed to BS 5534) 50mm x 25mm for rafters/ supports not exceeding 600mm centres (fixed to BS 5534) | |
| Tile nails | 38mm x 3.35mm | |
| Fixing Clips | Eaves, verge and tile clips | |
| Authority | BS EN 490 |
* The minimum recommended pitch and lap may be influenced by special circumstances, please contact the Technical Advisory Service.
